144 Core Outdoor Fiber Optic Cable GYTS Armored G652D Single Mode
Product Description
144 Core direct buried armored GYTS optical cable is a
communication cable with transmission speed like light. GYTA Armored Loose Tube Single Jacket/Single Armor fiber optic
cables are designed to provide high fiber counts with the
flexibility and versatility required for today's most demanding
installations, including duct and underground conduit.
Characteristic
1. The loose tube is filled with special gel, which protect the
optical fiber
2. With good mechanical properties and temperature characteristics
3. Anti-UV PE out sheath
4. Material of loose tube has good hydrolysis resistance and high
strength.
5. Specially designed compact cable structure to effectively
prevent casing from retracting
6. Take the following measures to ensure the waterproof performance
of the optical cable
--- Single steel wire center reinforced core
--- Filled with special Water-blocking material in loose tube
--- Moisture-proof layer of plastic-coated steel tape (PSP)
Features:
• Up to 288 fibers.
• Loose tube gel-filled construction for superior fiber protection.
• Aluminum tape armor to protect cable from mechanical damage.
• UV and waterproof design.
Application:
--- End users use directly cabling.
--- Directly installed into houses Aerial Installation Suitable for
Condominiuml Office Installation
--- Soft ,flexiable ,easy to lay and splice,and with big capacity
data transmission Meet various
requirements of market and clients
--- Access network, fiber to the home.
--- Anti-UV charateristics meet the requirements of relevant
standards
--- The mechanical charateristics meet the requirements of relevant
standards
--- Support the internet, CATV and telephone, Support more network
increase service in future
--- Good mechanical and enviromental characteristic
GYTS optic fiber cable Technology Specification:
| TYPE | G.652 | G.655 | 50/125μm | 62.5/125μm | Attenuation (+20℃) | 850nm | | | ≤3.0dB/km | ≤3.0dB/km | | 1300nm | | | ≤1.0dB/km | ≤1.0dB/km | | 1310nm | ≤0.36dB/km | ≤0.40dB/km | | | | 1550nm | ≤0.22dB/km | ≤0.23dB/km | | | Bandwidth (Class A) | 850nm | | | ≥500Mhz.km | ≥200Mhz.km | | 1300nm | | | ≥1000Mhz.km | ≥600Mhz.km | | Numerical Aperture | | | 0.200±0.015NA | 0.275±0.015NA | | Cable cut-off Wave lengh λ cc | ≤1260nm | ≤1480nm | | |
|
| Model | Fiber Count | Tubes | Fillers | Cable OD mm | Cable Weight kg/km | Tensile Strength Long/Short Term N | Crush Tesistance Long/Short Term N/100mm | Bending Radius Static/Dynamic mm | | 1062 | 2~6 | 1 | 4 | 10.2 | 116 | 600/1500 | 300/1000 | 10D/20D | | 1063 | 8~12 | 2 | 3 | | 1064 | 14~18 | 3 | 2 | | 1065 | 20~24 | 4 | 1 | | 1066 | 26~30 | 5 | 0 | | 1067 | 32~36 | 6 | 0 | 10.6 | 129 | 1000/3000 | | 1068 | 38~48 | 4 | 1 | 11.2 | 141 | | 1069 | 50~60 | 5 | 0 | 11.2 | 141 | | 1070 | 62~72 | 6 | 0 | 12.0 | 159 | | 1071 | 74~84 | 7 | 1 | 13.6 | 209 | | 1072 | 86~96 | 8 | 0 | 13.6 | 209 | | 1073 | 98~108 | 9 | 1 | 15.4 | 232 | | 1074 | 110~120 | 10 | 0 | 15.4 | 232 | | 1075 | 122~132 | 11 | 1 | 17.2 | 280 | | 1076 | 134~144 | 12 | 0 | 17.2 | 280 |
|
Structure:
Packing
FAQ
| Q1: Are you a factory or trading company? |
| A1: We are a manufacturer. |
| Q2: Can you put my brand name (logo) on these products? | | A2: Yes! The professional OEM services will be welcomed to us. Our
factory accepts to make the logo free for bulk orders. |
|
| Q3: Can you provide us more other products to us to help us to save
more shipping costs? | | A3: Yes. There’re kinds of Indoor Cables, Outdoor Cables, Coaxial
Cables, Telephone Cables, Fiber Optic Cables and Accessories will
be the main products line of Factory. The OEM bulk order will be
accept as well. |
|
Q4: What is your Warranty? | | A4: All the products will have 12 months Warranty |
| Q5: May I buy samples from you? | | A5: Yes! You are welcome to place sample order to test our superior
quality and services. |
Q6: Where is your factory located? How can I visit there? | A6:Our factory are located in Deyang city. | | You can fly to Sichuan international airport. And tell us your
flight No. We will arrange to pick you up. |
|
|
| Q7: How will you deliver my goods to me? | | A7: Your purchases will be delivered by DHL, UPS, FedEx, TNT, EMS
your door. Air Cargo and Sea Cargo, Direct line, Air Mail also be
accepted according to clients' request. |
|
| Q8: May I know the status of my order? |
A8: Yes .The order information and photos at different production
stage of your order will be sent to you and the information will be
updated in time. |
| Q9: What’s the leading time? How long do you need to prepare my
goods? | | A9: Delivery (no more than 200 rolls) will be arranged within 10-15
days after payment, and arrive you within about 1 month via sea
shipping. |
|
| Q10:What payment method do you accept? | | A10:T/T(Bank transfer), Western Union, Money Gram, Paypal, etc. |
|
|
