CAT6 unshielded Gigabit copper clad aluminum finished network cable

    Buy cheap CAT6 unshielded Gigabit copper clad aluminum finished network cable from wholesalers

    Buy cheap CAT6 unshielded Gigabit copper clad aluminum finished network cable from wholesalers
    • Buy cheap CAT6 unshielded Gigabit copper clad aluminum finished network cable from wholesalers
    • Buy cheap CAT6 unshielded Gigabit copper clad aluminum finished network cable from wholesalers
    • Buy cheap CAT6 unshielded Gigabit copper clad aluminum finished network cable from wholesalers

    CAT6 unshielded Gigabit copper clad aluminum finished network cable

    Ask Lasest Price
    Brand Name : Aitong
    Model Number : CAT6 UTP patch cord
    Certification : ISO9001
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 2000 Piece/Pieces per Day
    Delivery Time : 5-8 days
    • Product Details
    • Company Profile

    CAT6 unshielded Gigabit copper clad aluminum finished network cable

    CAT6 unshielded Gigabit copper clad aluminum finished network cable


    Features and Benefits


    • Designed and engineered with precision balance to offer ultimate headroom • High-end optimized performance to support the most bandwidth-intense applications, average 1Gbps and up to 10 Gbps. • Performance guaranteed to 250 MHz, highest up to 550 MHz.

    • Snagless cable boot make plugging and unplugging is easier.
    • Low MOQ starting at 50 Pcs. • Improved cable temperature rating (75°C Riser) for greater protection against increased operating temperatures and for high-wattage applications.
    • FLUKE Test Pass (Free FLUKE Test report for the quantity higher 1000 pcs).

    Applications


    • IEEE 802.3: 1000 BASE-T, 100 BASE-TX, 10 BASE-T, 2.5GBASE-T, 5GBASE-T, 10GBASE-T(less than 37m), POE & POE+ (up to IEEE802.3at Class 4, only for Performance Version)

    • ANSI/TIA 854: 1000 BASE-TX • CDDI, Token Ring, ATM • Digital Video • Broadband and Baseband Analog Video


    Standard Compliances


    • ISO/IEC 11801 • TIA/EIA-568-C.2 Category 6 • ANSI/ICEA S-90-661 Category 6 • NEMA WC63.1 Category 6 • RoHS Compliance for the Requirement of European Union Issued Directive 2002/95/EC
    • UL 444

    Product Description

    A new performance evaluation index is determined for Category 6 cables. Single core bare copper with specification of 23AWG is used as the conductor, polyethylene polymer material is used as the insulator, and the sheath material is flame retardant polymer material with color of gray; The twisted pair meets the requirements of international specifications (ISO / IEC), and its electrical characteristics exceed the requirements of class VI (cat. 6) international specifications. The cross isolation of the cable center ensures the next performance and reasonable construction bending radius. LSZH: stands for "low smoke zero halogen". Low smoke halogen-free material can meet the requirements of safety and environmental protection.


    Parameter


    Specifications
    Performance Version
    Regular Version
    Conductor
    24AWG
    (Customizable)
    24AWG
    (Customizable)
    Conductor Structure
    Stranded
    Stranded
    Conductor Material
    99.997% Bare Copper
    CCA
    Shield
    Insulation
    High Density Polyethylene (HDPE)
    Color Code
    • Pair 1: Blue-White/Blue
    • Pair 2: Orange-White/Orange
    • Pair 3: Green-White/Green
    • Pair 4: Brown-White/Brown
    Separator
    Cross-web (High Density Polyethylene)
    Rip Cord
    Applied longitudinally under jacket
    Jacket
    Flame Resistant PVC (PE or LSZH)
    Connector
    RJ45 UTP Gold-plated Contact
    Conector Color
    Colorless transparent or Blue transparent
    Mold Design
    Snagless Cable Boot or Non-snagless Cable Boot without tab
    Flame Rate
    CM (suitable for in-wall installation)
    Color
    Black, White, Gray, Blue
    Maximum Pulling Force
    20 KG
    18KG
    Function Distance
    0-100m
    0-50m
    Temperature Rating (˚C)
    Installation
    Operation
    0 to +60
    -30-75
    Bandwidth:
    Average
    Maximum
    1 Gigabit
    10 Gigabit (under 37m)
    1 Gigabit
    5 Gigabit (under 10m)
    Frequency:
    Average
    Maxinum
    0-250 MHz
    0-550 MHz
    0-250 MHz
    0-350 MHz


    Detail Images


    CAT6 unshielded Gigabit copper clad aluminum finished network cable


    CAT6 unshielded Gigabit copper clad aluminum finished network cable


    FAQ
    Q1: Are you a factory or trading company?
    A1: We are a manufacturer.
    Q2: Where is your factory located? How can I visit there?
    A2:Our factory are located in Deyang city.
    You can fly to Sichuan international airport. And tell us your flight No. We will arrange to pick you up.
    Q3: May I buy samples from you?
    A3: Yes! You are welcome to place sample order to test our superior quality and services.
    Q4: What is your Warranty?
    A4: All the products will have 12 months Warranty
    Q5:What payment method do you accept?
    A5:T/T(Bank transfer), Western Union, Money Gram, Paypal, etc.
    Q6: Can you put my brand name (logo) on these products?
    A6: Yes! The professional OEM services will be welcomed to us. Our factory accepts to make the logo free for bulk orders.
    Q7: May I know the status of my order?
    A7: Yes .The order information and photos at different production stage of your order will be sent to you and the information will be updated in time.
    Q8: What’s the leading time? How long do you need to prepare my goods?
    A8: Delivery (no more than 200 rolls) will be arranged within 10-15 days after payment, and arrive you within about 1 month via sea shipping.
    Q9: How will you deliver my goods to me?
    A9: Your purchases will be delivered by DHL, UPS, FedEx, TNT, EMS your door. Air Cargo and Sea Cargo, Direct line, Air Mail also be accepted according to clients' request.
    Q10: Can you provide us more other products to us to help us to save more shipping costs?
    A10: Yes. There’re kinds of Indoor Cables, Outdoor Cables, Coaxial Cables, Telephone Cables, Fiber Optic Cables and Accessories will be the main products line of Factory. The OEM bulk order will be accept as well.
