Indoor Wiring Unshielded UTP 305m CCA CAT5e Lan Cable 24 Awg Ethernet Cable

    Buy cheap Indoor Wiring Unshielded UTP 305m CCA CAT5e Lan Cable 24 Awg Ethernet Cable from wholesalers

    Buy cheap Indoor Wiring Unshielded UTP 305m CCA CAT5e Lan Cable 24 Awg Ethernet Cable from wholesalers
    • Buy cheap Indoor Wiring Unshielded UTP 305m CCA CAT5e Lan Cable 24 Awg Ethernet Cable from wholesalers
    • Buy cheap Indoor Wiring Unshielded UTP 305m CCA CAT5e Lan Cable 24 Awg Ethernet Cable from wholesalers

    Indoor Wiring Unshielded UTP 305m CCA CAT5e Lan Cable 24 Awg Ethernet Cable

    Ask Lasest Price
    Brand Name : Aitong
    Model Number : cat-5e-UTP
    Certification : ISO9001
    Price : As required
    Payment Terms : L/C, D/A, D/P, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 200 winding box day
    Delivery Time : 5-8 work days
    • Product Details
    • Company Profile

    Indoor Wiring Unshielded UTP 305m CCA CAT5e Lan Cable 24 Awg Ethernet Cable

    Indoor wiring unshielded (UTP) 305m CCA line 24awg standard Ethernet Cat5e Lan cable​


    Product description


    Cat 5e UTP CCA Cable is designed for high speed LANs including Gigabit Ethernet applications. The Cca LSZH sheath offers
    excellent fire performance making this the ideal choice in public buildings and other high risk locations, exceeding the requirements of
    BS6701:2016+A1:2017 for installation cables. When used with Cat5e panels and modules it gives the exceptional performance required for
    transmission over all four pairs.

    Connectix Cat 5e Cable is designed for high speed LANs including Gigabit Ethernet applications. The Cca LSZH sheath offers


    excellent fire performance making this the ideal choice in public buildings and other high risk locations, exceeding the requirements of BS6701:2016+A1:2017 for installation cables. When used with Cat5e panels and modules it gives the exceptional performance required for transmission over all four pairs.Construction

    • Suitable for Gigabit Ethernet applications
    • Supplied metre marked for easy installation
    • Pure copper cores
    • Excellent performance exceeding ANSI/TIA Enhanced
    • Category 5e specifications
    • 305m supplied in an easy pull boxes
    • In line with BS6701:2016+A1:2017 specifications
    • 25 Year System Warranty Available

    Appliacation

    • Exceeds ANSI/TIA-568B. 2 and ISO 11801 2nd Edition Class E Category 5e channel standards.
    • Exceed requirements of ANSI/TIA-568B. 2 and IEC 61156-5 Category 5e Component standards;
    • Meets requirements of IEEE 802.3af and IEEE 802.3at for PoE applications.
    • Foil shield reduces ingress of EMI interference to ensure cable performance at high frequency levels.
    • Length cable marking enable easy identification of remaining cable which reduces installation time and cable scrap.
    • Color Availability: Additional cable colors available.

    ▌Parameter


    ConstructionIndoor Wiring Unshielded (UTP) 305m CCA Wire 24awg Standard
    Impedance100 MHz +/- 15 Ω
    Operating temperature (T-T)-20˚C to +70˚C
    Conforms toIEEE 802.3: 10Base-T, 100Base-T, 1000 Base-T standards; ANSI/TIA 568C; ISO/IEC 11801; RoHS2002/95/EC
    Fire RatingCca s1a , d1 , a1
    Inner Conductor24 AWG plain copper
    InsulationHigh density polyethylene
    Colour CodePair 1: White/Blue-Blue/White Pair 2: White/Orange-Orange/White Pair 3: White/Green-Green/White Pair 4: White/Brown-Brown/White
    JacketFR-LSZH
    Overall Diameter5.4 +/- 0.4 mm
    Min. Bending Radius Installation44mm
    Min. Bending Radius Installed22mm
    DC Resistance< 9.4 Ω/100 m
    Velocity Ratio69%
    Installation temperature (T-T)0˚C to +50˚C

    Electrical Specifications

    DC Resistance< 9.4 Ω /100 m
    Velocity Ratio69%
    Operating Temperature Range-20 ̊C to +70 ̊C
    Installation Temperature Range0 ̊C to +50 ̊C
    Transfer Impedance (mΩ/m)1 MHz 10 MHz 30 MHz 1 00MHz

    Product Specifications


    Conforms toIEEE 802.3:1OBase-T.1OOBase-T, 10OO Base-T
    standards; ANSI/TIA 568C; ISO/IEC 11801;
    RoHS2002/95/EC, Cenelec EN5O173
    Fire Rating24 AWG plain copper
    lnner ConductorHigh density polyethylene
    Construction4 twisted pairs cabled together
    Colour CodePair 1: White/Blue-Blue/White
    Pair 2: White/Orange-Orange/White
    Pair 3: White/Green-Green/White
    Pair 4: White/Brown-Brown/White
    SheathFR-LSZH
    RAL ColourGreen -6018
    Overall Diameter5.4+/-0.4 mm
    Min. BendingRadius lnstallation44 mm
    Min. BendingRadius Installed22 mm

    ▌Product mix

    Indoor Wiring Unshielded UTP 305m CCA CAT5e Lan Cable 24 Awg Ethernet CableIndoor Wiring Unshielded UTP 305m CCA CAT5e Lan Cable 24 Awg Ethernet Cable

    Panking


     Indoor Wiring Unshielded UTP 305m CCA CAT5e Lan Cable 24 Awg Ethernet Cable Indoor Wiring Unshielded UTP 305m CCA CAT5e Lan Cable 24 Awg Ethernet CableCable weightGross weight
    9.3kg10kg
    Box size (CM)Specifications
    21.5×35×35305m/box

    Application scenario


    Indoor Wiring Unshielded UTP 305m CCA CAT5e Lan Cable 24 Awg Ethernet CableIndoor Wiring Unshielded UTP 305m CCA CAT5e Lan Cable 24 Awg Ethernet CableIndoor Wiring Unshielded UTP 305m CCA CAT5e Lan Cable 24 Awg Ethernet CableIndoor Wiring Unshielded UTP 305m CCA CAT5e Lan Cable 24 Awg Ethernet Cable
    Network TVDesktop computerNotebook computerPrinter
    Indoor Wiring Unshielded UTP 305m CCA CAT5e Lan Cable 24 Awg Ethernet CableIndoor Wiring Unshielded UTP 305m CCA CAT5e Lan Cable 24 Awg Ethernet CableIndoor Wiring Unshielded UTP 305m CCA CAT5e Lan Cable 24 Awg Ethernet CableIndoor Wiring Unshielded UTP 305m CCA CAT5e Lan Cable 24 Awg Ethernet Cable
    RouterSet top boxCabinetCamera

    Frequently asked question (FAQ)

    Q: Are you a cable and wire manufacturer?
    — Yes, we are a professional wire and cable manufacturer.

    Q: Can you offer a discount on cables?
    — The price is negotiable according to the specification and quantity.

    Q: Can you offer FREE samples?
    — Yes,FREE samples are available, you just take care of the freight fee.

    Q: What about your MOQ?
    — Usually, our MOQ is 5000 Meters, but we’ d love to talk about your MOQ.

    Q: Do you accept customize cables?
    — Yes, we are more than happy to make OEM and ODM for you.

    Q: How long is the lead time?
    — Usually it’s about 10-14 days.
