SYV5DF Shielded Coaxial Cable Wear Resistance 75ohms Video Coaxial Cable

    Buy cheap SYV5DF Shielded Coaxial Cable Wear Resistance 75ohms Video Coaxial Cable from wholesalers

    Buy cheap SYV5DF Shielded Coaxial Cable Wear Resistance 75ohms Video Coaxial Cable from wholesalers
    • Buy cheap SYV5DF Shielded Coaxial Cable Wear Resistance 75ohms Video Coaxial Cable from wholesalers
    • Buy cheap SYV5DF Shielded Coaxial Cable Wear Resistance 75ohms Video Coaxial Cable from wholesalers

    SYV5DF Shielded Coaxial Cable Wear Resistance 75ohms Video Coaxial Cable

    Ask Lasest Price
    Brand Name : Aitong
    Model Number : 5DF
    Price : USD 0.7-1.32 Meters $1.32
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 10000 Kilometer/Kilometers per Day
    Delivery Time : 5-8 work days
    • Product Details
    • Company Profile

    SYV5DF Shielded Coaxial Cable Wear Resistance 75ohms Video Coaxial Cable

    Coaxial Cable SYV5DF Shielded Cable Monitoring Cable Video Cable Coaxial Cable


    Product overview


    Coaxial cable refers to the cable with two concentric conductors and the conductor and shield layer sharing the same axis. The most common type of coaxial cable consists of a copper conductor insulated by an insulating material. On the outside of the inner insulating material is another ring conductor and an insulator. The entire cable is then enclosed by a sheath of polyvinyl chloride or teflon material.


    Features

    • PVC high quality insulation material
    • High insulation resistance, high voltage resistance and wear resistance
    • Life is long
    • softness
    • Resistance to stretch
    • Double shield anti-interference
    • Aluminum foil + aluminum magnesium wire two layer shielding
    • CCTV coaxial power line is easy to use

    Construction and Dimension


    Item
    RG59
    RG58
    RG6
    RG7
    RG11
    Material of inner conductor
    Cu
    Cu
    Cu
    Cu
    Cu
    Diameter of inner conductor(mm)
    0.81±0.02
    19*0.20±0.01
    1.00±0.02
    1.29±0.02
    1.63±0.02
    Material of dielectric
    Foam PE
    PE
    Foam PE
    Foam PE
    Foam PE
    Diameter of Dielectric(mm)
    3.66±0.15
    2.95
    4.57±0.01
    5.72
    7.11
    Material of Shield
    ALfoil+Al brading
    BC/TC braiding
    ALfoil+Al brading
    ALfoil+Al brading
    ALfoil+Al brading
    Coverage
    40%--95%
    95%
    40%--95%
    40%--95%
    40%--95%
    Diameter of 1st outer conductor
    3.9
    -
    4.9
    5.9
    7.52
    (mm)
    Diameter of 2nd outer conductor
    4.12
    --
    5
    -
    7.8
    Material of Jacket
    PVCPE
    PVCPE
    PVCPE
    PVCPE
    PVCPE
    Diameter of Jacket
    6.3
    4.95
    6.9
    8.1
    10.16

    RG59 Coax ConstructionOD/ (mm)
    ConductorSolid Copper0.81
    DielectricPhysical Foam Polyethylene3.66
    ShieldBonded Aluminum Foil+Aluminum BraidNom.4.10
    JacketPVC or Polyethylene6.1
    PVC

    RG 58 Cable Physical Characteristics
    Weight per5kg
    Minimum bend radius32mm
    Operating temperature rangePVC:-25℃ to +75℃
    PE:-45℃ to +80℃
    RoHS compliance2011/65/EU (RoHS)

    RG-59 Cable Electrical Characteristics
    Impedance75+/- 2 ohms
    Capacitance52pF/m. max
    Maximum voltage5000Volts
    Velocity of propagation85%
    Operating Frequency1GHz
    Screening effectiveness≥ 40dB (up to 1 GHz)
    Insulation resistance≥ 1 x 108MΩm
    Max. operating voltage≤ 3.0kVrms (at sea level)

    RG59 Attenuation
    Freq(MHz)Typical(dB/m)Max. CW power
    1000.105319
    3000.189184
    5000.249143
    7000.3121
    9000.346106
    10000.367101

    ▌Parameter


    SYV5DF Shielded Coaxial Cable Wear Resistance 75ohms Video Coaxial Cable

    projectMaterial ScienceDiameter (mm)
    1. Inner conductorBare copper wire1.02
    2. InsulatorFoamed polyethylene4.57
    3. Outer conductorSelf adhesive aluminum foil + aluminum magnesium wire braidingNom.5.22
    4. SheathPolyvinyl chloride (PVC)6.91
    Polyethylene (PE)

    goodsRG6 RG59 coaxial cable with power cord
    Minimum order quantity30000 meters
    Conductor materialCopper / CCS
    insulationFoam / solid PE
    Woven36W, 48W, 64W, 96w, 112W, 128W or customized
    JacketPVC

    Application
    SYV5DF Shielded Coaxial Cable Wear Resistance 75ohms Video Coaxial CableSYV5DF Shielded Coaxial Cable Wear Resistance 75ohms Video Coaxial CableSYV5DF Shielded Coaxial Cable Wear Resistance 75ohms Video Coaxial Cable
    Rack connection of equipment, transmission of closed-circuit television (CCTV), common antenna system (MATV) and color or monochrome RF monitor. These applications do not require the selection of precision video coaxial cables with particularly strict electrical tolerances. The characteristic resistance of video coaxial cable is 75 ohms, which is not optional. Physics has proved that the optimal attenuation characteristic of video signal occurs at 77 ohms. In low-power applications, the material and design determine that the optimal impedance of the cable is 75 ohms.

    Packaging:


    SYV5DF Shielded Coaxial Cable Wear Resistance 75ohms Video Coaxial Cable

    1. Standard Packaging:
    Rolled by wooden wooden drums. 2000m to 6000m/drum or other required.
    2. Sheath mark:
    The following printing(white hot foil indentation)is applied at 1meter intervals.
    a. Supplier: Guanglian or as customer required

    b. Standard Code(Product Type, Fiber Type,Fiber Count)
    c. Year of manufacture: 20 years
    d. Length marking in meters.

    Our Service:
    1. We are the one of biggest manufacture of cable in China and has more than 20 years manufacturing and selling experience.
    2. We accept OEM. The cable size and material are customized.
    Ur own logo and own design are welcome. We will produce
    according to your requirment and description;
    3. Please send us inquiry for more products info and we will
    give you feedback in 12 hours.

    FAQ

    Q1. Can I have a sample order for this product?
    A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

    Q2. What about the lead time?
    A: Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than

    Q3. Do you have any MOQ limit for sample order?
    A: Low MOQ, 1pc for sample checking is available

    Q4. How do you ship the goods and how long does it take to arrive?
    A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.

    Q5. How to proceed an order for the product?
    A: Firstly let us know your requirements or application.
    B.Secondly We quote according to your requirements or our suggestions.
    C.Thirdly customer confirms the samples and places deposit for formal order.
    D.Fourthly We arrange the production.
