    T-307H Fiber Optic Accessories Multifunctional Domestic Optical Fiber Fusion Splicer

    T-307H Multifunctional portable domestic optical fiber fusion splicer


    Description


    Optical fiber fusion splicer is mainly used for the construction and maintenance of optical cable in optical

    communication, so it is also called optical cable fusion splicer. The general working principle is to use a

    high-voltage arc to melt the sections of the two optical fibers while using a high-precision motion mechanism

    to gently advance the two optical fibers into one, so as to realize the coupling of the optical fiber mode fields.


    Features


    1. Four-motor core alignment
    2. Equipped with a lightweight five-in-one fixture, which is smaller than the usual fixture. Durable.
    3. Low splicing loss (SM:0.03dB/MM0.02dB/DS:0.05dB/NDS:0.05dB/G657E0.03Db/G654E0.01Db).
    The heating furnace supports five sizes of heat shrink tubing (20/30/40/50/60mm)
    3. Welding in 6 seconds, heating in 13 seconds, the number of welding heating is more than 120 times.
    4. In terms of performance parameters, it is better than most fusion splicers. With a small body and high integration,

    tumtec has made great efforts.


    Technical parameter


    Fiber typeSM (single mode), MM (multimode), DS (dispersion shift), NZDS (non-zero dispersion shift)
    Splice loss0.02dB(SM),0.01dB(MM),0.04dB(DS),0.04dB(NZDS)
    Return lossbetter than 60dB
    Operation modefully automatic, semi-automatic, manual
    Fiber alignmentCladding alignment
    Welding time≤6 seconds
    Heating time≤18 seconds
    MagnificationVertical dual display, magnification 360 times; horizontal dual display, 180 times magnification
    Image displayHigh-performance 5-inch full digital true color display, providing clear and delicate image display
    Optical fiber fixtureThree-in-one fixture: leather cable, 0.25mm, 0.9mm ordinary optical fiber, etc.
    Tension teststandard 2N
    Heat shrinktubing 60mm, 40mm and a series of heat shrink tubing
    The battery capacity6000mAh, 200 times of splicing is typical, and the charging time is about 3 hours (the splicing can be done while charging)
    Electrode lifetypically 3000~5000 times, electrode replacement is simple and convenient
    External interfaceUSB for easy data download and software update
    Power supplyBuilt-in lithium battery: 11.1V 6000mAh; external adapter: input AC 100~200V, output DC 13.5V/4.5
    Working Temperature-10℃~+60℃; Humidity: 0~95%RH (non-condensing); Altitude: 0~5000m
    Weight2.2kg (without battery)
    Host sizelength×width×height: 130mm×135mm×130mm
