    Gjyxfch-1b1.3 8 Type Self Supporting Fiber Optic Cable 2/4 Core Non Metallic FRP Reinforcer

    Ask Lasest Price
    Brand Name : Aitong
    Model Number : GJYXFCH-1B
    Certification : ISO9001,ISO9001/CE/RoHS
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T
    Supply Ability : 100KM/Day
    Delivery Time : 5-8 Days
    • Product Details
    • Company Profile

    Gjyxfch-1b1.3 8 Type Self Supporting Fiber Optic Cable 2/4 Core Non Metallic FRP Reinforcer

    Gjyxfch-1b1.3 Self-Supporting 8-Type Optical Fiber Outdoor 2/4-Core Non-Metallic FRP Reinforcer Cable FTTH Fiber


    Description


    As the name suggests, it is an optical fiber directly to the home. Specifically, FTTH refers to the installation of an optical network unit (ONU) at home users or corporate users, and is the type of optical access network application closest to the user in the optical access series except FTTD (Fiber to the Desktop).

    Characteristics

    • Make sure you have enough rice
    • Excellent stress resistance
    • Extremely fast transmission speed
    • Environmental protection, low smoke halogen free flame retardant sheath
    • EASY TO PEEL OFF, EASY TO CONNECT, EASY TO WORK.

    Features

    1. The cable is specially designed in elasticity, and is suitable for indoor wiring, optical fiber into the home and terminal installation, which often need to bend the cable
    2. The optical fiber is placed in the middle of two stiffeners and has excellent lateral compression and tensile resistance

    Cable Parametres

    Model No.Fiber count (core)Cable diametre (mm)Weight (kg/km)Tensile Strength Long/Short Term (N)Crush Resistance Long/Short Term (N)Bending Radius
    Static/Dynamic
    (mm)
    GJYXCH1(2.1±0.1)×(5.1±0.1)211500/2500500/130015/30
    GJYXCH2(2.1±0.1)×(5.1±0.1)211500/2500500/130015/30
    GJYXCH4(2.1±0.1)×(5.1±0.1)211500/2500500/130015/30

    Fiber TypeAttenuationOverfilled launch BandwidthEffective Modal Bandwidth10GB/S Ethernet link lengthMin Bending Radius
    Conditions1310/1550nm850/1300nm850/1300nm850nm850nm
    UnitdB/kmdB/kmMHZ.kmMHZ.kmmmm
    G652D0.36/0.2216
    G657A10.36/0.2210
    G657A20.36/0.227.5
    50/1253.0/1.0≥500/50030
    62.2/1253.0/1.0≥200/50030
    OM33.0/1.0≥1500/500≥2000≥30030
    OM43.0/1.0≥3500/500≥4700≥55030
    B1-OM33.0/1.0≥1500/500≥2000≥3007.5
    B1-OM43.0/1.0≥3500/500≥4700≥5507.5

    Gjyxfch-1b1.3 8 Type Self Supporting Fiber Optic Cable 2/4 Core Non Metallic FRP Reinforcer


    We produce and test cable comply with following standard

    Mechanical Performance
    Max Tension PerformanceIEC 60794–1-2-E
    Max. Operation TensionIEC 60794–1-2-E1
    Crush TestIEC 6079 –1-2-E3
    Impact TestIEC 60794–1-2-E4
    Repeated BendingIEC 60794–1-2-E6
    Torsion TestIEC 60794–1-2-E7
    Cable bendIEC 60794–1-2-E11A
    Attenuation CoefficientITU-T G.652
    Structural TestIEC-60793-1-20
    Environmental Performance
    Temperature CyclingIEC 60794–1-2-F1
    Water PenetrationIEC 60794–1–2-F5B
    Filing Compound FlowIEC 60794-1-E14

    Application

    Gjyxfch-1b1.3 8 Type Self Supporting Fiber Optic Cable 2/4 Core Non Metallic FRP Reinforcer


    Why Choose Us?


    Gjyxfch-1b1.3 8 Type Self Supporting Fiber Optic Cable 2/4 Core Non Metallic FRP Reinforcer


    Production and Qulaity Test

    Gjyxfch-1b1.3 8 Type Self Supporting Fiber Optic Cable 2/4 Core Non Metallic FRP Reinforcer
