    1 Core FTTH Fiber Optic Cable G657a Double Steel Fire Resistant

    Ask Lasest Price
    Brand Name : Aitong
    Model Number : GJXH-1B
    Certification : ISO9001
    Price : $0.02-0.04/meter
    Payment Terms : L/C, T/T, T/T, Western Union, MoneyGram
    Supply Ability : 150000KM/mouth
    Delivery Time : 5-8days
    • Product Details
    • Company Profile

    1 Core FTTH Fiber Optic Cable G657a Double Steel Fire Resistant

    FTTH Fiber Optic Cable 1 Core Double Steel KFRP Strength Member

    Core Double Steel FTTH Fiber Optic Cable


    Detailed Product Description


    GJXH cables are suitable for indoor environments and are mainly used for FTTH installations. The optical fiber is in the center of the cable, and two parallel FRP elements reinforce the cable. These elements are then surrounded by a sheath made of low-smoke material, which is halogen-free and fire-resistant.


    Characteristics

    1. Small bending radius and good flexibility, which can meet various indoor wiring environments of fiber-to-the-home
    2. Small diameter, lightweight and practical
    3. Simple and reasonable structure, good compressive, tensile and anti-aging properties
    4. "8" groove design, easy to peel off the sheath, easy to install and maintain​

    General Specifications:


    Cable TypeFTTH(Drop Cable)
    Fiber TypeSM G657A1/ SM G657A2
    ApplicationFTTH, LAN
    Recommended installation methodsAerial
    EnvironmentIndoor
    Temperature Range-40℃ to 70℃

    Fiber Specifications:


    Fiber styleUnitSM
    G652D
    SM
    G657A1
    SM
    G657A2
    conditionnm1310/15501310/15501310/1550
    attenuationdB/km≤0.36/0.23≤0.35/0.21≤0.35/0.21
    Dispersion1310nmPs/(nm*km)≤18≤18≤18
    1550nmPs/(nm*km)≤22≤22≤22
    Zero dispersion wavelengthnm1312±101312±101300-1324
    Zero dispersion slopeps/(nm²×Km)≤0.091≤0.090≤0.092
    PMD Maximum Individual Fiber[ps/√km]≤0.2≤0.2≤0.2
    PMD Design Link Valueps/(nm²×Km)≤0.08≤0.08≤0.08
    Fiber cutoff wavelength λcnm≧1180,≤1330≧1180,≤1330≧1180,≤1330
    Cable cutoff wavelength λccnm≤1260..........
    MFD1310nmum9.2±0.49.0±0.49.8±0.4
    1550nmum10.4±0.810.1±0.59.8±0.5
    Step(mean of bidirectional measurement)dB≤0.05≤0.05≤0.05
    Irregularities over fiber length and point discontinuitydB≤0.05≤0.05≤0.05
    Difference backscatter coefficientdB/km≤0.03≤0.03≤0.03
    Attenuation uniformitydB/km≤0.01≤0.01≤0.01
    Cladding diameterum125.0±0.1124.8±0.1124.8±0.1
    Cladding non-circularity%≤1.0≤0.7≤0.7
    Coating diameterum242±7242±7242±7
    Coating/chaffinch concentrically errorum≤12.0≤12.0≤12.0
    Coating non circularity%≤6.0≤6.0≤6.0
    Core/cladding concentricity errorum≤0.6≤0.5≤0.5
    Curl(radius)um≥4≥4≥4

    1 Core FTTH Fiber Optic Cable G657a Double Steel Fire Resistant

    Standard Color Identification of Fiber

    No.1234
    ColorBlueOrangeGreenBrown

    Cable Design

    ItemDescription
    Model NoGJXH/GJFXH
    1. Fiber count1 Core , 2 Core, 4 Core
    2. Cable Diameter3.0*2.0mm
    3. Cable Weight11.5KGS/9.5KGS
    4. Strength member
    - MaterialSteel/FRP
    - Diameter0.45mm
    5. Outer Sheath
    - MaterialLSZH (Black/white)
    6. Sheath marking
    - Type of markingLaser printing

    Packing

    ItemsDescription
    Cable length1KM or 2KM per reel
    Package materialdrum+carton
    Package size1KM31.5*21*32.5cm
    2KM34.5*28*35cm

    FAQ


    Q1: How long has your company been doing this?
    A1: More than 20 years.We are not only produce fiber optical cable but also produce optical fiber and related tools .

    Q2: Can you produce cable as our requirements?
    A2: Of course .We can supply different types of products according to your requirements with reasonable prices .

    Q3: Where is your factory ?
    A3: Our factory is located in DONGGUAN City, GUANGDONG Province, China.
    Q4: Do you accept the OEM order and how many is the MOQ?
    A4: Yes,we warmly welcome your OEM order.To achieve customer's satisfaction,we accept sample order, even one Piece.

    Q5: How about the cable's quality?
    A5: Our factory is approved by ISO9001 quality management system and including STARF,CE,CPR,TLC certifications at list.We have a series of equipment and instruments to make sure reliable quality of our products.


    1 Core FTTH Fiber Optic Cable G657a Double Steel Fire Resistant

    Q1: Where is your factory ?
    A1: Our factory is located in DONGGUAN City, GUANGDONG Province, China.Optical Fiber Leather Cable GJXH-1B Optical Fiber Indoor 1-
